Discover machines suitable for every need.
Max outreach, m:
4.2
Lifting capacity at full reach and max pressure, w/o grapple and rotator, kg:
190
Lifting capacity at 4 m reach and max pressure, w/o grapple and rotator, kg:
x
Crane weight without support leg and valve block, kg:
185
Max outreach, m:
4,2
Lifting capacity at full reach and max pressure, w/o grapple and rotator, kg:
540
Lifting capacity at 4 m reach and max pressure, w/o grapple and rotator, kg:
x
Crane weight without support leg and valve block, kg:
360
Max outreach, m:
5,4
Lifting capacity at full reach and max pressure, w/o grapple and rotator, kg:
410
Lifting capacity at 4 m reach and max pressure, w/o grapple and rotator, kg:
600
Crane weight without support leg and valve block, kg:
400
Max outreach, m:
6,3
Lifting capacity at full reach and max pressure, w/o grapple and rotator, kg:
355
Lifting capacity at 4 m reach and max pressure, w/o grapple and rotator, kg:
655
Crane weight without support leg and valve block, kg:
415
Max outreach, m:
6,7
Lifting capacity at full reach and max pressure, w/o grapple and rotator, kg:
520
Lifting capacity at 4 m reach and max pressure, w/o grapple and rotator, kg:
1040
Crane weight without support leg and valve block, kg:
620
Max outreach, m:
7,1
Lifting capacity at full reach and max pressure, w/o grapple and rotator, kg:
580
Lifting capacity at 4 m reach and max pressure, w/o grapple and rotator, kg:
1115
Crane weight without support leg and valve block, kg:
710
Max outreach, m:
7,5
Lifting capacity at full reach and max pressure, w/o grapple and rotator, kg:
660
Lifting capacity at 4 m reach and max pressure, w/o grapple and rotator, kg:
1440
Crane weight without support leg and valve block, kg:
940
Max outreach, m:
8,5
Lifting capacity at full reach and max pressure, w/o grapple and rotator, kg:
560
Lifting capacity at 4 m reach and max pressure, w/o grapple and rotator, kg:
1270
Crane weight without support leg and valve block, kg:
950
Max outreach, m:
8,7
Lifting capacity at full reach and max pressure, w/o grapple and rotator, kg:
490 (8.4 m)
Lifting capacity at 4 m reach and max pressure, w/o grapple and rotator, kg:
1235
Crane weight without support leg and valve block, kg:
995
Max outreach, m:
7,8
Lifting capacity at full reach and max pressure, w/o grapple and rotator, kg:
880
Lifting capacity at 4 m reach and max pressure, w/o grapple and rotator, kg:
1950
Crane weight without support leg and valve block, kg:
1220
Max outreach, m:
8,7
Lifting capacity at full reach and max pressure, w/o grapple and rotator, kg:
690
Lifting capacity at 4 m reach and max pressure, w/o grapple and rotator, kg:
1770
Crane weight without support leg and valve block, kg:
1280
Max outreach, m:
9,4
Lifting capacity at full reach and max pressure, w/o grapple and rotator, kg:
650
Lifting capacity at 4 m reach and max pressure, w/o grapple and rotator, kg:
1750
Crane weight without support leg and valve block, kg:
1310
Max outreach, m:
10,1
Lifting capacity at full reach and max pressure, w/o grapple and rotator, kg:
680
Lifting capacity at 4 m reach and max pressure, w/o grapple and rotator, kg:
2000
Crane weight without support leg and valve block, kg:
1760
Cranes |
PALMS 1.42 | PALMS 2.42 | PALMS 2.54 | PALMS 3.63 | PALMS 3.67 | PALMS 4.71 | PALMS 5.75 | PALMS 5.85 | PALMS 5.87Z | PALMS 7.78 | PALMS 7.87 | PALMS 7.94 | PALMS X100 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Series | 1 | 2 | 2 | 3 | 3 | 4 | 5 | 5 | 5 | 7 | 7 | 7 | X |
| Max outreach, m | 4.2 | 4,2 | 5,4 | 6,3 | 6,7 | 7,1 | 7,5 | 8,5 | 8,7 | 7,8 | 8,7 | 9,4 | 10,1 |
| Max working pressure, bar | 180 | 195 | 215 | 195 | 215 | 215 | 215 | 215 | 215 | 240 | 240 | 240 | 240 |
| Brutto lifting torque at maximum pressure, kNm | 11,5 | 26 | 29 | 36 | 51 | 57 | 69 | 69 | 63 | 96 | 96 | 96 | 112 |
| Lifting capacity at full reach and max pressure, w/o grapple and rotator, kg | 190 | 540 | 410 | 355 | 520 | 580 | 660 | 560 | 490 (8.4 m) | 880 | 690 | 650 | 680 |
| Lifting capacity at 4 m reach and max pressure, w/o grapple and rotator, kg | x | x | 600 | 655 | 1040 | 1115 | 1440 | 1270 | 1235 | 1950 | 1770 | 1750 | 2000 |
| Slewing torque, kNm | 2,1 | 7,8 | 7,8 | 9 | 12 | 15 | 17 | 17 | 17 | 21 | 21 | 21 | 30 |
| Pillar slewing angle, degrees | 330 | 370 | 370 | 370 | 370 | 370 | 380 | 380 | 340 | 380 | 380 | 380 | 380 |
| Rotator maximum load, kN | 10 | 45 | 45 | 45 | 45 | 45 | 60 | 60 | 60 | 60 | 60 | 60 | 100 |
| Crane weight without support leg and valve block, kg | 185 | 360 | 400 | 415 | 620 | 710 | 940 | 950 | 995 | 1220 | 1280 | 1310 | 1760 |
| Recommended oil flow, L/min | 10-20 | 20-35 | 20-35 | 20-35 | 30-45 | 45-70 | 50-90 | 50-90 | 50-90 | 60-120 | 60-120 | 60-120 | 120 |
