Max working pressure, bar
215
Brutto lifting torque at maximum pressure, kNm
63
Lifting capacity at full reach and max pressure, w/o grapple and rotator, kg
490 (8.4 m)
Lifting capacity at 4 m reach and max pressure, w/o grapple and rotator, kg
1235
Pillar slewing angle, degrees
340
Rotator maximum load, kN
60
Crane weight without support leg and valve block, kg
995
Recommended oil flow, L/min
50-90
